HYR Flexible bearing mainly bear alternating stress. It is easy to have a certain deformation when it matches with cams, because its section is very thin. Inner ring, outer ring and rolling elements adopt High-carbon chromium bearing steel. Cage adopts integrated nylon cage.
Product Paramenters
Model | Main dimension
| Rated value |
d
| D | B | C | R | Max radial deformation(mm) | Input speed (r/min) | Mass(g) |
HYR-14 | 25.07 | 33.896 | 6.35 | 6.095 | 0.3 | 0.8 | 3000 | 10 |
HYR-14D | 25.07 | 33.796 | 4 | 4 | 0.3 | 0.8 | 3000 | 8 |
HYR-17 | 30.3 | 41.722 | 6.68 | 6.16 | 0.3 | 0.9 | 3000 | 15 |
HYR-17D | 30.3 | 41.722 | 4.6 | 4.6 | 0.3 | 0.9 | 3000 | 13 |
HYR-20 | 35.56 | 49.068 | 8.13 | 7.24 | 0.3 | 1.0 | 3000 | 30 |
HYR-20D | 35.56 | 49.068 | 5.2 | 5.2 | 0.3 | 1.0 | 3000 | 25 |
HYR-25 | 45.212 | 61.334 | 6.3 | 9.015 | 0.3 | 1.0 | 3000 | 40 |
HYR-25D | 45.212 | 61.134 | 6.35 | 6.35 | 0.3 | 1.0 | 3000 | 32 |
HYR-32 | 58.928 | 79.748 | 8.64 | 11.81 | 0.3 | 1.2 | 3000 | 105 |
HYR-32D | 58.932 | 79.56 | 8.64 | 8.64 | 0.3 | 1.2 | 3000 | 95 |
HYR-40 | 71.12 | 98.171 | 10.29 | 14.475 | 0.6 | 1.5 | 3000 | 209 |
HYR-50 | 88.9 | 122.707 | 12.7 | 18.085 | 1 | 2.0 | 3000 | 415 |
HYR-65 | 117.856 | 159.312 | 15.88 | 23.495 | 1 | 2.0 |
|
|
