Cylindrical roller bearings with no ribs in the inner ring or outer ring. The inner ring and outer ring can move relative to each other in the axial direction, so they can be used as free-end bearings. Cylindrical roller bearings with double ribs on one side of the inner ring and outer ring and a single rib on the other side of the ring can withstand a certain degree of axial load in one direction. Generally, steel plate stamping cages or copper alloy machined solid cages are used. However, some use polyamide molded cages.

The rollers of cylindrical roller bearings are in line contact with the raceway and have large radial load capacity. It is not only suitable for bearing heavy loads and impact loads, but also suitable for high-speed rotation. It also improves the lubrication conditions in the contact area between the roller end face and the rib, improving the performance of the bearing. Bearing Man’s WeChat account is worth paying attention to! Generally suitable for large and medium-sized electric motors, rolling stock, machine tool spindles, internal combustion engines, generators, gas turbines, reduction gearboxes, rolling mills, vibrating screens, and lifting and transportation machinery.

1. The rollers and raceways are in line contact or trimmed line contact. They have large radial load-bearing capacity and are suitable for withstanding heavy loads and impact loads.

2. The friction coefficient is small, suitable for high speeds, and the limit speed is close to that of deep groove ball bearings.

3. N type and NU type can move axially, can adapt to changes in the relative position of the shaft and housing caused by thermal expansion or installation errors, and can be used as free end supports.

4. The processing requirements for the shaft or seat hole are relatively high. After the bearing is installed, the relative deflection of the outer ring axis must be strictly controlled to avoid contact stress concentration.

5. The inner or outer ring can be separated for easy installation and removal.
