In the crossed roller bearing, since the cylindrical rollers are arranged perpendicular to each other on the 90° V-shaped groove rolling surface through the spacer, the crossed roller bearing can bear radial load, axial load and moment load, etc. multi-directional loads. The size of the inner and outer rings is miniaturized, and the extremely thin form is close to the limit of small size, and has high rigidity, so it is more suitable for the joints and rotating parts of industrial robots, the rotating table of machining centers, the rotating parts of manipulators, Precision rotary tables, medical equipment, measuring instruments, IC manufacturing equipment and other equipment.

Rotational accuracy: spacers are installed between the vertically arranged rollers in the bearing, which prevents the inclination of the rollers and the mutual friction between the rollers, and reduces the rotational moment. In addition, compared with conventional steel cages, there is no edge stress concentration or locking of the rollers. At the same time, because the inner ring or outer ring is divided into two structures, the bearing clearance can be adjusted, and even if a preload is applied, it can rotate smoothly with high precision.

Types of crossed cylindrical roller bearings:

RB type (integral inner ring, separate outer ring) This model is the basic type of crossed roller bearings. The outer ring is divided into two pieces, and the inner ring is an integral structure, which is more suitable for occasions that require the rotation accuracy of the inner ring.

RE type (separate inner ring, integral outer ring) is also the basic type of crossed roller bearings. Its external dimensions are the same as those of RB type, but the structure is a whole outer ring, and the inner ring is divided into two pieces. Circle rotation accuracy occasions.

RU type (integrated inner and outer rings, with mounting holes), since the outer ring and inner ring have mounting holes, there is no need to fix the flange and support seat during installation. In addition, since the outer ring and the inner ring are of integral structure, the installation has almost no influence on the performance, so stable rotation accuracy and torque can be obtained, and it is suitable for the occasion where the outer ring and the inner ring rotate.

Type RA (integral inner ring, separate outer ring, ultra-thin) This type is a compact type that reduces the thickness of the inner and outer rings of Type RB to the limit. The structure is the same as that of Type RB. Parts with compact design, such as the rotating part of the robot arm.

CRBH type (integrated inner and outer ring, ultra-thin), this model is ultra-thin RU, due to the ultra-thin design and the outer ring and inner ring have no mounting holes, flanges and support seats are required for installation. In addition, since the outer ring and inner ring are integral structures, installation has no effect on performance, so stable rotation accuracy and torque can be obtained. It is suitable for occasions where the outer ring and inner ring rotate but require miniaturization.

SX type (integral inner ring, separate outer ring, ultra-thin), in the case of the same journal, this type has a smaller cross-sectional size than the RB type, due to the ultra-thin design, the outer ring and inner ring are not installed Holes, flanges and support seats are required for installation, and are suitable for applications where the inner ring rotates.
